Jiangsu Yourshine is a first-class cold storage insulation materials manufacturer and a cold storage energy-saving program supplier. Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. We can give you a professional suggestion based on your application. And about the size, the panel thickness, the equipment, all of them can be customized.


Product Highlights

+ MORE

Overview

CONTACT US

Technical Information

Jiangsu Yourshine is a first-class cold storage insulation materials manufacturer and a cold storage energy-saving program supplier. Polyurethane insulation board design for cold room, the main steel structure to facilitate construction. We can give you a professional suggestion based on your application. And about the size, the panel thickness, the equipment, all of them can be customized.


Name Freezer
Functions Frozen Food Storage
Model Number Cold Room Refrigeration Unit
Voltage Customized
Power(W) Cold Room Specifications
Cold room door hinged , sliding, swing door
Wall panel PU sandwich
Warranty 1 year
PU panel thickness 40/50/75/100/120/150/180/200/250mm

Specification
Width Standard width 960mm, or customized and maximum 1200mm.
Length As customers' requirements, maximum 12000mm.
Thickness 50 mm ≥ 15ºC
75 mm ≥ 10ºC
100 mm ≥ -15ºC
150 mm ≥ -25ºC
200 mm ≥ -35ºC
250 mm ≥ -45ºC
The most suitable thickness will be suggested according to the size and temperature requirements, or customers’ requirements.
Surface material 0.326~0.8mm Color steel sheet
0.4~0.8mm stainless steel sheet
0.5~3mm embossed aluminum sheet
0.5~2mm galvanized steel sheet
Core material PU(polyurethane ) / PUR(polyisocyanate ) / PIR(polyisocyanurate)
Joint system Cam lock, tongue & groove, hook & pin

1) Customized design
2) Water-proof
3) Meets safety requirements
4) Energy saving.
5) Longer lifetime.
6) Resistant to termites and rodents.
7) Easy to install – saving cost of installation time • High performance on insulated panel.


Technical Parameters
Core material PU PUR PIR
Density 40±2 kg/m3 40±2 kg/m3 40±2 kg/m3
Heat Conductivity ≤0.024 W/m. k ≤0.024 W/m. k ≤0.022 W/m. k
Compressive Strength ≥150 N/cm2 ≥150 N/cm2 ≥160 N/cm2
Combustion performance B2 grade B2 grade B1 grade
The bond strength between sandwich core layer and panel >0.1 >0.1 >0.1

Similar Products

Cold Storage for Slaughterhouse

Cold Storage for Slaughterhouse

At our cold storage facility, we understand the critical importance of maintaining optimal temperature conditions for the storage of meat products from slaughterhouses. Our state-of-the-art cold storage solutions are designed to provide a controlled environment that safeguards the quality, freshness, and safety of your valuable meat inventory.

Cold room for mushroom cultivation

Cold room for mushroom cultivation

Cold room / Cold storage for fruits and vegetables need to be maintained in specific temperature and humidity. In addition to proper temperature and humidity, fruits and vegetables should be always stored separately. Some fruits do not ripen once harvested while others will continue to ripen after harvest because they naturally produce ethylene, which speeds the ripening process of vegetables.

Meat chiller

Meat chiller

It is used to sell and display kind of meat, cooked foods, milk products, and cold drink and so on, the running temperature is 0~5°C. There are some specifications: Normal length is 2000mm,3500mm,can be jointed freely, and length can be customized by clients' need.

Frequently Asked Questions

We are factory which is established in 1993 with more than 30 years industry experience

Our factory is located in Jiangsu.

For standard size models, we have plenty of material in stock, less than 500pcs, 3-7 day is ok: For customized models, the delivery date depends on the quantity that you want.

50% of deposit , and 50% balance against by T/T before delivery.

Generally, we will use EXW or CFR. Other terms are negotiated

We don't have MOQ limitation. 1 pc can be shipped out as the sample.

We will provide detailed installation instruction for every type of product. lf needed, we can also ask engineers to teach you by phone, face-time or video.

Sure. it is acceptable.

From 3 years to 5 years.

Yes, you can. T/T is also welcome.

Yes, we could offer the sample for free charge but do not pay the cost of freight.

Yes, all products support customization. The size, color, material, etc. of the panel and door, all could be customized according to the needs and requirements of clients.
